Description
One Glance at the Industrial Videoscope VUMAN®
Enhanced Visibility with the new VUSCREEN Control Unit
The VUSCREEN control unit of the VUMAN® E3 video endoscope is ergonomic and robust at the same time. For transport, simply attach the VUSCREEN to the housing on the back of the VUMAN®. There are various ways to position the control unit during an inspection. For example, you can attach it directly to the VUMAN®, either on top or on the back of it, carry it on the shoulder strap around your neck or simply put it down on a work bench or the ground. This way, you are no longer bound to stand directly next to your industrial videoscope when inspecting, but are able to move around freely. Even lengthy inspections do not pose a problem thanks to the transreflective 10.4” touchscreen TFT display with LED backlight, True Color and native resolution of 1440 x 1080 px.
Take Full Control with the X-WAY Articulation
Our pneumatic X-WAY probe articulation of this industrial videoscope allows a full 4-way articulation (up/down/left/right). Use the joystick to manually adjust direction and degree of the probe articulation. The probe articulation is driven by a computer-controlled micro compressor, making external compressed air sources unnecessary when operating the industrial videoscope VUMAN.
Industrial Videoscope with Interchangeable Probes
Thanks to our V3 interchangeable probe concept and the wide range of short and long range video probes, the VUMAN® E3 combines several industrial videoscopes in one. If you need to use several probes for one inspection, you can simply interchange them on site and switch between the probes needed. This smart concept saves you the cost of purchasing several videoscope systems. Furthermore, it makes cost-saving, modular repairs possible. Also, in case of contamination, you can simply remove the probe and replace it by a new one, instead of replacing the entire industrial videoscope system.
Always Optimally Equipped with the V3 Video Probes
Select the interchangeable probes that are most suitable for your applications. With the industrial videoscope VUMAN® E3/E3+ it is very easy to interchange the video probes directly on site. Choose between different probe lengths and diameters, articulating or non-articulating. With articulating video probes up to 30 m length, the VUMAN® E3/E3+ is especially advantageous for applications that require a long endoscope range.
In general, we are offering VUMAN® video probes with diameters from 6.1 mm to 12.7 mm and in lengths between 5 m and 30 m. Moreover, there are several optical adapters with which you can change direction of view (DOV) and field of view (FOV) of your videoscope camera. Additionally, it is possible to connect other external video endoscopes such as the VISIO system to our VUMAN®.
Articulating 6 mm Probe with up to 30 m Length
The smallest 4-way articulating long range industrial videoscope
The VUMAN E3/E3+ is an exceptional industrial videoscope! Our absolute highlight is the 6.1 mm thin, articulating video probe with up to 30 m working length. This extraordinary video probe enables you to inspect even very narrow applications with 30 m length and to still bend the camera head if necessary. Due to the integrated remote focus and the optionally available optic adapters, you will achieve an incredible image resolution even at only 2 mm distance to the test object.
The long video endoscope VUMAN® E3 is the best industrial videoscope of its kind. No matter which kind of application you need it for: this long range endoscope system will help you to quickly and efficiently accomplish the inspection task.
In the following fields, the VUMAN video borescope is especially convincing:
- Nuclear industry
- Pharmaceutical industry
- Construction
- Offshore
- Security
- Power generation
- Marine / naval
- Industrial turbines
